Slurry Pump For Gold Mine, Gold Mining Slurry Pump, centrifugal slurry pump

FOB Reference Price:Get Latest Price
US $1,000-5,999 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
YONJOU
Model Number:
HM
Theory:
Centrifugal Pump
Structure:
Single-stage Pump
Usage:
slurry and other similar liquid
Power:
Electric
Standard or Nonstandard:
Standard
Fuel:
electric
Pressure:
High Pressure
Application:
slurry pump
Production Capacity:
1000sets/year
SupplyAbility
SupplyAbility:
1000 Set/Sets per Year
Packaging & Delivery
Packaging Details
standard plywood or carton for each gold mining slurry pump
Port
Ningbo, Shanghai
Lead Time :
20 days for slurry pump
Product Description



Specification:

1.Model: AH
2.Material: high chrome alloy or rubber or ceramic
3.Flow Rate: 10.8-5400m3/h
4.Head: 3-118m
5.Certification: ISO9001:2008

6.Suit for heavy slurry in agriculture,petrochem,manufacturing,energy and mining.





Advantage:
1) Decrease electricity consumption and increase pump life
Our uniquely designed pumps limit slurry contact thus the efficiency is significantly higher and hence very big conventional slurry pumps can be replaced by a pump with a 20% of more smaller motor without affecting pumping performance. If energy bills and high cost of ownership is of concern, these pumps are the answer.

2) Lime and ash applications
Lime and ash pumping applications are particularly difficult for centrifugal slurry pumps because acceleration inside the pump causes the slurry to clump together into a solid clay degrading performance. We have a unique solution proven to work more efficiently and outlast conventional pumps.

3) High viscosity liquids
Superior throughput rates compared to gear and vane pumps using a unique new design. Great for bitumen, all emulsions and fats.



Product Details:

Equivalent
type for reference
TypeMaterial qualityClear water performance
Protect
cover
ImpellerQHnη(NPSH)r
CapacityHeadSpeedEffciency
(m³/h)(m)(r/min)(%)(m)
4/3C-AHTD75-100CMM86.4-1989-521000-2200714-6
4/3D-AHTD75-100D
4/3C-AHTD75-100CRURU79.2-1805-34.5800-1800593-5
4/3D-AHTD75-100D
4/3C-AHTD75-100CMM97.2-194.49-531000-220055
4/3D-AHTD75-100D
4/3E-HHTD75-100EMM126-25212-97600-1400502-5

Note:
1. RU stands for rubber material, and M stands for wear-resistign alloy material.
2. Recommended flow range is 50%Q'≤Q≤110%Q'(Q'≈the corresponding flow at the highest efficiency point)
3. NPSH refers to the corresponding NPSH value of the recommended Q point at the maximum.
