Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: YONJOU diesel engine water pump
  • Model Number: 250S-60/4135AG
  • Theory: Centrifugal Pump
  • Structure: Multistage Pump, Diesel Engine+Fire Pump Group
  • Usage: Water
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Diesel
  • Pressure: High Pressure
  • Application: Maritime, mine, flood, fire figiting,irrigation,
  • Material: Cast Iron,Stainless steel, Bronze
  • Certificate: CE/ISO9001:2000/TUV
  • Seal: Mechanical seal
  • Diesel engine's brand: chinese or cummins, Deutz ....
  • Tailer: can be equipped according to client
  • Color: All ( according to client )
  • OEM: Available

Packaging & Delivery

Packaging Details packing:standard export plywood case per diesel engine water pump set
demension:1200*300*260mm
Weight:500kg~2000kg per each agricultural irrigation diesel engine water pump set
Horizontal Multistage price of diesel water pump set, diesel engine water pump
Delivery Time Normally two weeks according to quantity

 Horizontal Multistage price of diesel water pump set, diesel engine water pump

Product Description



Technical Data of  diesel engine water pump





Product NameHorizontal Multistage Centrifugal Pump
Capacity6.3-450m3/h
Head75-685 m
Motor Power5.5-1050 kw





Product Introduction of diesel engine water pump set



D and DG pump is a horizontal multistage centrifugal pump, which is fit for transportation clean water (impurity content

is less than 1%,granularity is less than 0.1mm)and or other liquid with physical and chemical characters like clean water.

D pump transportation medium temperature is not more than 80C, which is fit for mine discharge and water feeding to

factory and city.

DG pump transportation medium temperature should not be more than 105C, which is fit for water feeding to small boiler

or similar applications.







Model Series    Application
D

used to deliver clear water without solid praicles used to miner with the temperatrue range from  0°C~80°C,

The inlet is horizontal direction.

DM

used to deliver liquid with less solid particles or miner with the temperatrue range from 0°C~+80°C

The inlet is horizontal direction.

DG

used to deliver clear water without solid particles or liquid similar to clear water physically

 and chemically with the temperatrue range form -20°C~+150°C. The inlet is perpendicularly direction.

DY

used to deliver oil products without solid or liquid similar to water

with the temperatrue range from-20°C~+400°C. The inlet is horizontal direction.

DF

used to deliver corrosive liquid without solid with the temperatrue range

 from -20°C~+150°C. The inlet is horizontal direction.



All kind type pump discharge is perpendicnlarly direction.

The shaft of all kind type pump can be with soft packing or mechanical seal.

The material through which liquid passes is made from cast iron or bronze or steelness.



Structure Drawing

















  Agricultural Irrigation Diesel Water Pump, moveble Diesel water pump, diesel fuel pump





Application Area of agricultural irrigation diesel water pump



♦  Construction

♦  Industrial

♦  Municipal

♦  Agricultural

♦  Mining

♦  Dewatering

♦  Industrial Waste

♦  Sewage

♦  Oil Field

♦  Petrochemical

♦  Paper Mills

♦  Processing





Pump Specification:



Diesel information



Basic Configuration of agricultural irrigation diesel water pump



Speed SensorGovernor
Pressure gauge2 sets 12V battery
Water temp sensorPump quality certificate
Common baseDiesel engine handle book
Base fuel tankHeat exchanger
Lubricating oil pressureLubricating heater
Water pressure gaugePressure gage





Diesel engine specification







Drive VariationCummins,Deutz,Ricardo,Perkins or Chinese Diesel
Power Range50HP~1066HP
Diesel drivingWater cooled,air cooled
Cylinder2 or 4
Cylinder diameter95,96,100,102,105,110,113
Stroke115,125,130,135
Displacement3.26~9.49L
Engine Oil Capacity13L,17L
Fuel consumption218,224,231,251.6,258.4
N.weight












Packaging & Shipping

 1. Standard export plywood case

 2. Steel frame construction
